Wednesday, June 07, 2006
COMPRESSION
You may find “QCIF”, “CIF”, “Half D1”, “D1” from our specification of IP camera (TP-IP68M) and MPEG-4 DVR (TP-S104MDR, TP-S108MDR & TP-S1016MDR).
Do you know, what is that mean? We make a chart for you reference.
| ompression | Resolution (NTSC) | Resolution (PAL) | Remark |
| FULL D1 | 720 x 480 | 720 x 576 | DVD Quality |
| HALF D1 | 352 x 480 | 352 x 576 | MPEG-2 Quality |
| CIF | 352 x 240 | 352 x 288 | Quarter of Full D1 |
| QCIF | 176 x 120 | 176 x 144 | Quarter of CIF |
Monday, June 05, 2006
IP CAMERA
Our IP camera (TP-IP68M) use MPEG-4 compression technology. It supported protocol like TCP/IP, HTTP, ARP, PPPoE, DDNS, DHCP, RTP/RTSP, IGMP. The frame rate reach to 30 FPS at 720x480 and max resolution to Full D1.
Maybe you still not understand IP camera very well. You can image IP camera is a “Video Server with CCD Camera”. Video server emphasize network transmission and browse function, but it doesn’t have storage function. When you bworse picture from IP camera, you can record picture to PC, that your PC become to DVR. You can save money to buy DVR.
Thursday, June 01, 2006
MPEG-4 DVR (4 or 8 channels)
⊙ Multiplex operation for doing back-up, recording, playback and remote playback at the same time.
⊙ Remote live viewing, recording, playback and controlling via Ethernet through LAN network and Internet browser.
⊙ Dual NTSC/PAL system through auto detection of Camera 1 input.
⊙ Fast and large image backup via Flash Driver with USB connector.
⊙ Each camera can be configured by different resolution, quality and IPS.
⊙ Easy operation by IR Remote Controller (optional) and Jog Shuttle simply just as a VCR.
⊙ Motion detection by individual or all cameras in different detection areas and sensitivities.
